Ducted split, stable cooling at 60 °C
TCL Tropical High ESP Duct
Built for tropical and desert climates, this concealed ducted split delivers stable cooling at 60 °C ambient with up to 200 Pa external static pressure, constant air volume and a 245 mm slim body. Twin and triple systems, Wi-Fi, BMS and dry-contact control are supported.
Max. rated cooling ambient
60 °C
- 60 °C
- Stable cooling ambient
- 200 Pa
- External static pressure
- 245 mm
- Slim body (18–36K)
- 80 m
- Piping length · 40 m lift
Overview
Engineering highlights
Specification summary
- Product family
- Light Commercial
- Capacity range
- 18K–60K Btu/h
- Cooling operating range
- Up to 60 °C
Figures from TCL global product pages. Specifications vary by model and region — confirm against the submittal for your project. tcl.com
- 01
Precise ±1 °C control
Full-DC inverter design with a high-precision electronic expansion valve holds the set temperature within ±1 °C.
- 02
200 Pa & constant air volume
Up to 200 Pa ESP on 36–55K models supports long ducts; the fan motor adapts to duct resistance to keep airflow constant.
- 03
Healthier air
Evaporator self-cleaning, an optional silver-ion and activated-carbon health filter and an optional fresh-air module.
- 04
Service-friendly
Motor removal from below, a two-screw control board, side-pull filter, optional 1,200 mm condensate pump and refrigerant recovery into the outdoor condenser.
- 05
Twin / triple systems
One outdoor unit can drive two or three indoor units that switch together — ideal for open-plan spaces.
Typical applications
Malls & RetailHigh heat loads, long trading hours and rooftop plant that bakes in the sun all summer.
Offices & TowersLong vertical piping, zoned tenancy control and energy codes that reward every percentage point.
Villas & CompoundsConcealed ducting, majlis comfort, clean façades and outdoor units that never give up in August.
Restaurants & F&BKitchens next to dining rooms, glass shopfronts and diners who notice every draught.
